CZJ-B SeriesVibration Monitor
CZJ-B SeriesVibration Monitor Operation Manual
1．GeneralCZJ-B is a kind of indispensable test and protection deviceused for rotating machinery equipment such as fan, compressor andsteam turbine generator, etc. It can match with SZ series speedtransducer to continuously monitoring and measuring the absolutevibration peak – peak value or the vibration speed of bearings inall kinds of rotating machinery. There is current output which isdirect proportion with the measure value. It can directly connect toDCS, PLC System and the non-paper recorder. When vibration is overlimit value, it can provide automatically the alarm relay switchvolume contact point output.This product has high precision, stable performance, stronganti-interference and high reliability. It is widely used for power,machinery, chemical industry and metallurgic industry, etc., andsuitable for the monitor system design for small and middle scalerotating machinery device. There are pan fixed type and wall hangedtype for customer’s option in this CZJ-B series vibration monitors.This monitor can match with the model SZ-6i local installed typeelectromagnetic speed transducer so as to be used in the explosionproof site. The explosion proof site certificate No. is CNEx09.2137Uand the explosion proof mark is Exib II BT4.2．ProductsCZJ-B2 Vibration Intensity MonitorCZJ-B3 Vibration Intensity MonitorCZJ-B3G Vibration Intensity Monitor （Wall hanged meter）CZJ-B4 Vibration MonitorCZJ-B4G Vibration Monitor（Wall hanged meter）
3．Technical parameter 3.1 Vibration Monitor - 2 - 3.1.1 Input signal: SZ series electromagnetic type speed transducer. 3.1.2 Measure range: CZJ-B2/B4/B4G: 0 ～ 200μm (pk-pk); CZJ-B3/B3G : 0 ～ 20mm/s (RMS); precision degree: full measure range ±1.0% (at 25℃ ); 3.1.3 Display method: 3 digital LED display, CZJ- B2/B4/B4G insolation 1, CZJ-B3/B3G insolation 0.1. 3.1.4 Frequency range: CZJ-B2/B4/B4G: 14 ～ 100Hz, CZJ-B3/B3G 11 ～ 100 Hz. 3.1.5 Current output: Active DC 4 ～ 20mA; precision: full range ±1.0% (at25 ℃ ), max. load: 500Ω. 3.1.6 Buffer output: Transducer aboriginality signal output 3.1.7 Alarm setting: set anyway in full range. 3.1.8 Alarm output: relay switch output, NO contact point, capacity resistance load AC250V/2A, DC28V/2A. 3.1.9 Alarm delay: 0.1s, 1s, 3s (If no special requirement, the manufacturer sets up for 1s. ) 3.1.10 Use condition: temperature 0 ～ 50℃ , storage temperature:- 20 ～ 60℃ relative humidity:20 ～ 90% (non-condensation)，there is no corrosive matter and no strong magnetic field on surrounding. 3.1.11 Power source: （85 ～ 265）VAC; 220VAC. 3.1.12 Overall size: ■ Pan installation meter: W160×H80×D225（mm）, Opening hole size: W152×H76（mm）. ■ Wall hanged meter:L290×W190×T92（mm）, Installing size: bottom 170 ×H272mm (Triangle).
3.2 Transducer:3.2.1 Test condition: temperature 20℃ ±5℃ ; Relative humidity ≤ 80%; No strong magnetic field interference at environment;3.2.2 Sensitivity: SZ–6, SZ–6B, SZ-6i: 50mV/mm/s, error: ±5%;- 3 - SZ-4V, SZ-4H: 28.5mV/mm/s, error: ±5%;3.2.3 Frequency: SZ–6, SZ–6B, SZ–6i: 10Hz ～ 500Hz; SZ-4V, SZ-4H: 4 ～ 1000Hz;3.2.4 Self vibration freq.: about 10Hz;3.2.5 Measurable vibration amplitude: ≤ 2000μm(P-P) ;3.2.6 Max. acceleration: 10g3.2.7 Measurement direction: SZ–6, SZ–6B, SZ-6i (Vertical orhorizontal)；SZ–4V (Vertical)；SZ–4H (horizontal)3.2.8 Use environment:temperature (-30 ～ 120)℃ ;Relative humidity ≤ 95% (non-condensation);No corrosive, no strong magnetic field in the surrounding;3.2.9 Overall size: SZ–6, SZ–6V, SZ-6H: Φ28×76(mm); SZ–6B: Φ31.5×78(mm); SZ–6i: Φ35×78(mm);3.2.10 Installation method: fix the bottom of transducer on themeasured vibration point with bolts.
1．GeneralCZJ-B is a kind of indispensable test and protection deviceused for rotating machinery equipment such as fan, compressor andsteam turbine generator, etc. It can match with SZ series speedtransducer to continuously monitoring and measuring the absolutevibration peak – peak value or the vibration speed of bearings inall kinds of rotating machinery. There is current output which isdirect proportion with the measure value. It can directly connect toDCS, PLC System and the non-paper recorder. When vibration is overlimit value, it can provide automatically the alarm relay switchvolume contact point output.This product has high precision, stable performance, stronganti-interference and high reliability. It is widely used for power,machinery, chemical industry and metallurgic industry, etc., andsuitable for the monitor system design for small and middle scalerotating machinery device. There are pan fixed type and wall hangedtype for customer’s option in this CZJ-B series vibration monitors.This monitor can match with the model SZ-6i local installed typeelectromagnetic speed transducer so as to be used in the explosionproof site. The explosion proof site certificate No. is CNEx09.2137Uand the explosion proof mark is Exib II BT4.2．ProductsCZJ-B2 Vibration Intensity MonitorCZJ-B3 Vibration Intensity MonitorCZJ-B3G Vibration Intensity Monitor （Wall hanged meter）CZJ-B4 Vibration MonitorCZJ-B4G Vibration Monitor（Wall hanged meter）
3．Technical parameter 3.1 Vibration Monitor - 2 - 3.1.1 Input signal: SZ series electromagnetic type speed transducer. 3.1.2 Measure range: CZJ-B2/B4/B4G: 0 ～ 200μm (pk-pk); CZJ-B3/B3G : 0 ～ 20mm/s (RMS); precision degree: full measure range ±1.0% (at 25℃ ); 3.1.3 Display method: 3 digital LED display, CZJ- B2/B4/B4G insolation 1, CZJ-B3/B3G insolation 0.1. 3.1.4 Frequency range: CZJ-B2/B4/B4G: 14 ～ 100Hz, CZJ-B3/B3G 11 ～ 100 Hz. 3.1.5 Current output: Active DC 4 ～ 20mA; precision: full range ±1.0% (at25 ℃ ), max. load: 500Ω. 3.1.6 Buffer output: Transducer aboriginality signal output 3.1.7 Alarm setting: set anyway in full range. 3.1.8 Alarm output: relay switch output, NO contact point, capacity resistance load AC250V/2A, DC28V/2A. 3.1.9 Alarm delay: 0.1s, 1s, 3s (If no special requirement, the manufacturer sets up for 1s. ) 3.1.10 Use condition: temperature 0 ～ 50℃ , storage temperature:- 20 ～ 60℃ relative humidity:20 ～ 90% (non-condensation)，there is no corrosive matter and no strong magnetic field on surrounding. 3.1.11 Power source: （85 ～ 265）VAC; 220VAC. 3.1.12 Overall size: ■ Pan installation meter: W160×H80×D225（mm）, Opening hole size: W152×H76（mm）. ■ Wall hanged meter:L290×W190×T92（mm）, Installing size: bottom 170 ×H272mm (Triangle).
3.2 Transducer:3.2.1 Test condition: temperature 20℃ ±5℃ ; Relative humidity ≤ 80%; No strong magnetic field interference at environment;3.2.2 Sensitivity: SZ–6, SZ–6B, SZ-6i: 50mV/mm/s, error: ±5%;- 3 - SZ-4V, SZ-4H: 28.5mV/mm/s, error: ±5%;3.2.3 Frequency: SZ–6, SZ–6B, SZ–6i: 10Hz ～ 500Hz; SZ-4V, SZ-4H: 4 ～ 1000Hz;3.2.4 Self vibration freq.: about 10Hz;3.2.5 Measurable vibration amplitude: ≤ 2000μm(P-P) ;3.2.6 Max. acceleration: 10g3.2.7 Measurement direction: SZ–6, SZ–6B, SZ-6i (Vertical orhorizontal)；SZ–4V (Vertical)；SZ–4H (horizontal)3.2.8 Use environment:temperature (-30 ～ 120)℃ ;Relative humidity ≤ 95% (non-condensation);No corrosive, no strong magnetic field in the surrounding;3.2.9 Overall size: SZ–6, SZ–6V, SZ-6H: Φ28×76(mm); SZ–6B: Φ31.5×78(mm); SZ–6i: Φ35×78(mm);3.2.10 Installation method: fix the bottom of transducer on themeasured vibration point with bolts.
