WFD-600D infrared thermometer

Operating Instruction   VER  22.06

http://www.cn-kehai.com

一. Overview

WFD-600D infrared thermometer is an intelligent high-precision non-contact digital display thermometer. It uses the infrared radiation energy of the measured object to determine the temperature of the object. The measured distance is proportional to the size of the target being measured. The measurement range is divided into several temperature segments. The instrument shows intuitive reading, stable performance, fast response, simple operation, convenient installation and adjustment. Integrating optical, mechanical, microcomputer and electronic technology, it is an ideal non-contact thermometer.

WFD-600D infrared thermometer can be widely used in metallurgy, machinery, ceramics, glass and other industries. It is suitable for temperature measurement in furnace, heating furnace, billet, steel, ladle (tundish) and other occasions. It has the advantages of fast response speed and non-contact measurement.

二.the main characteristics

1. Transmission type fixed focal length optical system.

2. In order to meet the needs of users, the measurement range is divided into several temperature segments.

3. It has real-time value, average value, peak value and automatic ambient temperature compensation.

4. The circuit adopts high speed and low power consumption 8-bit single chip microcomputer as the central processor, and adopts CMOS circuit to make the whole machine work current

Small and reliable operation.

5. The infrared temperature measuring system is simple in structure, designed into an integrated structure, easy to install and debug.

6. The temperature probe is equipped with air source cooling device to reduce objective dust and ensure measurement accuracy.

Seven. Optional water-cooled sleeve allows the meter to be used in high temperature environments.

8. The infrared probe has a mounting bracket and a fixed base, and the bracket can be adjusted at 45° Angle.

三. Technical indicators

1. Measuring range: 0~1000℃ (according to the site situation, combined with user needs to determine the measuring range)

2. Calibration accuracy: ±0.5%±1℃ (upper limit of measurement temperature) (blackbody calibration)

3. Repeatability: ±0.5%±1℃ (upper limit of measured temperature) (blackbody calibration)

4. Distance coefficient: L/D=50 L - distance from probe to target, D - spot diameter

5. Response time: 1 second (adjustable according to site conditions)

6. Working range: 8~14μm

7.. Emission rate: 0.1~1.0 (continuously adjustable)

8. Temperature resolution: 1℃

9. Display value: 4 digit LED light emitting digital tube display. 10. Use environment: See Table 1

11. Power supply: 24VDC power supply 12. Weight: Probe 8Kg
